No fan design;

- harmonic;

The basic function of inverter: DC power into AC power, pure sine wave;

- standby function: users can use standby function to reduce power consumption from the inverter;

A variety of communication interfaces: RS485, RJ45 network port, Meter and so on, to meet the different environment of communication needs;

The inverter: built-in clock timing mode can be flexibly set load working time;

FLASH - 4M bytes can be stored for at least 5 years operating data system;

- with the OWRELY family, Smart Meter, Owrely-RD controller, easy realization of photovoltaic power generation system.

Puresine Lite PP-200A-12/24 PP-450A-12/24/48

@25 C 150VA 300VA continuous power

The 30 minute power @25 C 200VA 450VA

5 seconds power @25 C 350VA 750VA

Rated DC input voltage: DC input voltage range of 12V: 9.5-15.5V 12V: 9.5-15.5V

24V: 21-32V 24V: 21-32V

48V: 42-64V 48V: 42-64V

Pure sine wave output waveform

Cooling radiator

Rated output voltage and frequency of 220Vac + 5% and 110Vac + 5%, 50Hz & 60Hz

Communication port RS485 (isolation) /USB interface RS485 (isolation) /USB/ network port

Electrical protection reverse polarity protection, overload and short circuit protection, high voltage and low voltage disconnect protection, high temperature protection circuit breaker

The highest efficiency of 12V: 92%

24V: 93%

48V: 94%

Working environment temperature -45 - +55 C

The working environment humidity of 100% non condensing

The level of protection IP20

The weight of 5.67kg

Dimension 265*190*126mm

3 year warranty

Optional accessories: Owrely-RD RTS temperature sensor, relay driver
